Description
The Vortech Compact wastewater pumping station is equipped with high-quality submersible pumps, ideal for both foul and surface water applications. It can be customized to meet your specific requirements.
These pump chambers are crafted from virgin polyethylene, ensuring superior durability and resistance to corrosion. The compact design makes them perfect for installation in confined spaces such as basements and cellars. Each system comes with a standard high-level alarm, and we also offer optional battery backup control systems for critical situations.
This system is ideal for the following applications:
- Outbuildings
- Annexes
- Extensions
- Cellars
- Pool houses
The Dutypoint Vortech Compact pumping station is a fully assembled package, ready for immediate installation. For detailed installation guidelines and to schedule professional Dutypoint commissioning, please contact us.
Important Note: Dutypoint Vortech polyethylene underground chambers are not suitable for installations where groundwater levels may exceed 2 meters above the chamber base. It is essential to follow the provided installation instructions.
Chamber Specification:
| Chamber Model | Compact 10 | Compact 20 |
| Internal Diameter (m) | 0.6 | 0.6 |
| Depth (m) | 1 | 2 |
| Nominal Capacity (L) | 280 | 550 |
| Access Opening | 450 Ø | 450 Ø |
Pump Specifcation:
| Pump Model | A05 | V05 | G10 |
| Application | Grey Water | Foul or Grey Water | Foul Water |
| Power Supply | 230v Single Phase | 230v Single Phase | 230v Single Phase |
| Kw Rating | 0.4 kw | 0.55 kw | 1 kw |
| Full Load Current | 3.3 Amps | 4.2 amps | 6.4 amps |
| Impeller Type | Vortex | Vortex | Grinder |
| Solids Passage | 10mm | 50mm | N/A |
| Max flow | 3.5 l/s | 4.5 l/s | 2.2 l/s |
| Max Head | 11m | 7m | 20m |
| Final Discharge Connection | 2″ BSP Male | 2″ BSP Male | 1.5″ BSP Male |
